Ports used by Cobwebb Document Management

Scroll Prev Top Next More

When there is a Firewall between your PC and the IBM i, certain ports need to be open when using Cobwebb Document Management.

Application

Ports

Cobwebb Designer

3772, 3773

Cobwebb Docstore

6443 (HTTPS), 6400 (HTTP)

IBM i Access

449, 8471-8476 (see table below for details)

5250 Emulation

23

Cobwebb FTP

21 (Others may be required if Passive FTP is enabled on the IBM i, which it almost always is)

The following is a summary of the main IBM i Access ports that may be significant - for the full list please see the IBM Support page.

PC Function

Ports

Server Mapper

449

Database Access

8471 (Used by Kofax validation)

Data Queues

8472

IFS Access using IBM i Navigator

8473

Network Printers

8474

Remote Command

8475

Signon Verification

8476

Example Error

The following is an error received when Exporting your Design from the Cobwebb Designer using sockets

Failed to Create Data Channel, Error Code is: 100xx

Reason - This was because port 3772 had been unblocked but port 3773 had not. Firewalls etc. need both ports (3772 & 3773) unblocked for Cobwebb Designer Export to work when the Use Sockets Server option is used. The PCSRVI (SOXSVR) job, running in the CPPD Subsystem, listens for connections on port 3772. When a file store request is made, a separate connection is created on port 3773.

Test Connection to an IBM i Port using TELNET

In the following examples please replace <server_address> with the DNS Name or IP Address of your IBM i.

Open a Command Prompt on your PC.

Port not open scenario

Enter:

telnet <server_address> 3773

Response:

Connecting To <server_address>...Could not open connection to the host, on port 3773: Connect failed

Port open scenario

Enter:

telnet <server_address> 3772

Response:

Accepted - Black screen
